ARS MODEL 1100STD MUSIC MIXER [ARS MODEL 1100STD]

MODEL1100 Music Mixer

2CHANNEL TABLE TOP MIXER


MODEL1100 MUSIC MIXER PRO PROFESSIONAL

ARS MODEL 1100 DJ Mixer is a Japanese made,
4ch. rotary mixer with world's first 3band hybrid isoeq
Hi-eq Mid-eq Low -Iso on each channel.
This 4 channel High Quality Rotary DJ Mixer has a 3 band Isolator on the master.
Potentiometer and Switch are All ALPS .
A long time in the development phase this mixer is a beautiful example of Japanese hand made precision workmanship.
Highly recommended.


It is designed with purist ideals with only essential features.

ARS 1100 has 3 band hybrid iso-eq hi-eq mid-eq low-iso on each channel

and 3band Iso on the master.

The Master Isolators can be boost of cut from +18db ~ -∞.

The Ch hi-eq mid-eq can boost or cut from +12db ~ -12db. LOW-ISO boost of cut from +6db ~ -∞.

Each channel has Post Fader Send. also Return and Effect Loop.

* Due to the Model-1100 is designed for a professional use, The body is no power switch to avoid accidentally power off while playing.

* Minimizing the power noise by designing the All circuit board and the power circuit board independently and setting them apart.



[SPEC]
Frequency Response: +-1dB 20Hz-20Khz
Input: 2 x Phono: 47K Ohm /2 x Line: 20K Ohm
House Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Booth Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Effect Loop: RCA Unbalanced Impedance 20K Ohm
Effect Loop Output: RCA Unbalanced Impedance 600 Ohm
Send Output: RCA Unbalanced Impedance 600 Ohm
Retrun: RCA Unbalanced Impedance 20K Ohm
Isolator Frequency Response:
3band hybrid isoeq 1-2Ch /Low-ISO /MID-EQ/HI-EQ
Master 3Band Iso: 10 – 300 Hz / 300 – 3000 Hz / 3000 – 20000Hz boost of cut from +18db ~ -∞.


Headphone Monitor Trim: Cue-Mix-Pgm
Power Consumption: 20w
Power Requirement: US-115V/EU-230V(Selectable)
Dimensions: (W)220 x (H)250 x (D)100 mm
Front Panel Color: Black
Spec Seat: Manufacturer site

Other Images

  • Ac power supply BOX
ARS MODEL 1100STD MUSIC MIXER [ARS MODEL 1100STD]

Selling Price: 281,000JPY

Prices vary according to options.

Weight: 12kg

Case Size (Frontage x Depth x Height)(mm)515X415X200
2TYPE: 9100/1100
Color: Black
Mass(g)4300g

Material Main Body: Polypropylene (PP)
Option CASE for 9100/1100:

Selling Price: 281,000JPY

Quantity:
You can roughly check the price in your currency with a currency converter below.
Since we accept the payment through PayPal, the conversion rates differ depends on PayPal's conversion rates.
