ARS MODEL 4200 MUSIC MIXER Black face Final Edition [ARS MODEL 4200BL]

MODEL4200 Music Mixer BL Final Edition


Model4200 Final Edition Limited to 300 units 4ch music mixer.


ARS MODEL 4200 DJ Mixer is a Japanese made,All hand crafted DJ mixer.
It is the result of our pursuit for pure sound quality.
It is designed with purist ideals with only essential features.
It gives a focus on the role of DJ mixers as the “music mixing tool”


Avoiding all other features that are the source of sound deterioration.
On the rotary faders, we selected original custom curve to deliver smooth and intricate mixes between 4 Channel – 3 Phono, 5 CD/Line, inputs.
Strikingly smooth operation feel.
Offering thick punchy bass and fine high-frequency sound, an overall sound character of MODEL 4200 is warm and deep.
Simple design, with front panel offered in 2 colors; Silver and Black.

* No power switch avoiding accidentally turning power off while playing.
* Minimizing the power noise by designing the main circuit board and the power circuit board independently and setting them apart.



[SPEC]
Frequency Response: +-1dB 20Hz-20Khz
Input: 3 x Phono: 47K Ohm / 5 x Line: 20K Ohm
House Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Booth Output:RCA Unbalanced Impedance 600 Ohm/ XLR Balanced Impedance 50 Ohm
Effect Loop: RCA Unbalanced Impedance 20K Ohm
Effect Loop Output: RCA Unbalanced Impedance 600 Ohm
Send Output: RCA Unbalanced Impedance 600 Ohm
Retrun: RCA Unbalanced Impedance 20K Ohm


Headphone Monitor Switch: Cue-Mix/Pgm
Power Consumption: 25w
Power Requirement: US-115V/EU-230V(Selectable)
Dimensions: Front Panel 2U (W)482.6x(H)88x(D)200 mm
Front Panel Color: Black
Spec Seat: Manufacturer site
